| Appearance | Gray |
| Dimension | 130 mm × 94 mm × 34 mm (5.11" × 3.70" × 1.34") |
| Operating Conditions | 0°C to 40°C (32°F to 104°F), Humidity: 10% to 95% (non-condensing) |
| LED Indicator | Green |
| Input | 185 to 240 VAC, 50 Hz to 60 Hz |
| Output | 12 VDC/1 A per channel |
| Ripple & Noise 150 mVp-p | 0.15 Vp-p (150 mV) |
| AC Input Connector | C8 |
| DC Output Connector | DC Plug: grid terminal |
| Storage Conditions | -40°C to 80°C (-40°F to 176°F), Humidity: 5% to 95% (non-condensing) |
| Cable Length Compensation | Normal: 12 VDC Long: 13.5 VDC Ex-Long: 15 VDC |
