Camera
Image Sensor | 1/3" Progressive Scan CMOS |
Max. Resolution | 2560 × 1440 |
Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON) |
Shutter Time | 1/3 s to 1/100,000 s |
Day & Night | IR cut filter |
Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360° |
Lens
Focal Length & FOV | 2.8 mm, horizontal FOV 98.5°, vertical FOV 53.1°, diagonal FOV 115.9°; 4 mm, horizontal FOV 78.3°, vertical FOV 42.8°, diagonal FOV 91.2° |
Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
Aperture | F1.6 |
Lens Mount | M12 |
Iris Type | Fixed |
Depth of Field | 2.8 mm: 1.4 m to ∞; 4 mm: 1.4 m to ∞ |
DORI
DORI | Fixed lens: 2.8 mm D: 63.4 m, O: 25.2 m, R: 12.7 m, I: 6.3 m; 4 mm D: 78.0 m, O: 31 m, R: 15.6 m, I: 7.8 m |
Illuminator
Supplement Light Type | IR, White Light |
Supplement Light Range | Up to 30 m |
IR Wavelength | 850 nm |
Smart Supplement Light | Yes |
Video
Main Stream | 50 Hz: 12.5 fps (2560 × 1440, 1920 × 1080, 1280 × 720); 60 Hz: 15 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
Video Compression | Main stream: H.265 |
Video Bit Rate | 32 Kbps to 8 Mbps |
H.265 Type | Main Profile |
Bit Rate Control | CBR, VBR |
Audio
Audio Compression | G.711ulaw |
Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw) |
Audio Sampling Rate | 8 kHz / 16 kHz |
Environment Noise Filtering | Yes |
Network
Simultaneous Live View | Up to 6 channels |
API | ISAPI, SDK |
User/Host | Up to 32 users; 3 user levels: administrator, operator, and user |
Client | Hik-Connect |
Mobile Communication
Standard | LTE-TDD |
Frequency | EU: LTE-FDD: B1/3/5/7/8/20/28; LA: LTE-FDD: B2/3/4/5/7/8/28/66 |
Uplink and Downlink Data Rate | Cat 1, uplink: 5.1 Mbps, downlink: 10.3 Mbps |
SIM Card Type | Nano SIM |
Image Settings | Brightness, contrast, white balance, saturation, sharpness |
Day/Night Switch | Day, Night, Auto, Schedule |
Image Enhancement | BLC, HLC, 3D DNR |
Wide Dynamic Range (WDR) | Digital WDR |
Interface
On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
Built-in Microphone | Yes, 1 built-in microphone |
Reset Key | Yes |
Built-in Speaker | Yes, 1 built-in speaker |
Event
Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)) |
Linkage | Notify surveillance center, trigger recording, trigger capture, audible warning, upload to memory card |
General
Power | 5 V, 2 A |
Material | Plastic |
Dimension | Ø81.6 mm × 221.3 mm (Ø3.2" × 8.7") |
Package Dimension | 320 mm × 228 mm × 148 mm (12.6" × 9.0" × 5.8") |
Weight | Approx. 480 g (1.1 lb.) |
With Package Weight | Approx. 1540 g (3.4 lb.) |
Startup and Operating Conditions | 0 °C to 50 °C (32 °F to 122 °F). Humidity 95% or less (non-condensing) |
General Function | Mirror, flash log |
Storage Conditions | -20 °C to 25 °C (-4 °F to 77 °F). Humidity 70% or less (non-condensing) |
Flashing Light | Yes |
Battery
Battery Type | Lithium |
Capacity | 9000 mAh (3.7 V) |
Max. Charging Voltage | 8.4 V |
Battery Voltage | 6 V to 8.4 V |
Operating Temperature | Charging: 0°C to 45°C (32°F to 113°F); Discharging: -20°C to 55°C (-4°F to 131°F) |
Cycle Lifetime | Cap(800th) ≥ 80% |
Approval
RF | CE-RED: EN 301489-1 V2.1.1 (BT or 2.4G); EN 301489-17 V3.1.1 (BT or 2.4G); EN 300328 V2.1.1 (BT or 2.4G); EN 62311:2008 (BT or 2.4G) |
EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, EN 50121-4:2016+A1:2019 |
Safety | CB: IEC 62368-1:2014+A11; CE-LVD: EN 62368-1:2014/A11:2017 |
Environment | CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; Reach: Regulation (EC) No 1907/2006 |
Protection | IP66: IEC 60529-2013 |
Solar Power
Solar Panel Type | Monocrystalline silicon solar panel |
Power Consumption | 8 W |
Solar Panel Dimensions & Weight | 263.8 × 171.7 × 18.5 mm / 450 g |
Working Temperature | -40°C to 85°C (-40°F to 185°F) |
Protection | IP65 |
