| Tunnel Size | 660mm Wx504 mm H |
| Appearance and Dimension | 2195mm x 902 mm x 1362.5 mm (86.42" x 35.51" x 53.64") |
| Max. load | 150 kg (330.69 lb) |
| Conveyor Height | 700mm |
| Conveyor speed | 0.22 m/s |
| Consumption | ≤0.8 kw |
| Penetration | 30mm standard(140KV generator/Default shipping model), 38 mm optional(160KV generator), 40+mm by customize |
| Power Supply | 220 VAC (+ 10% to 15%), 50 Hz (±3 Hz) |
| Wire resolution | 38AWG standard(140KV generator/Default shipping model), 40AWG optional(160KV generator) |
| Spatial resolution | Vertical: 1.0 mm (0.04") Horizontal: 1.0 mm (0.04) |
| Working Humidity | 10％~95％No Condensing |
| Working Temperature | 5 °C to 40 ° C (41 °F to 104 °F) |
| Power Consumption | ≤0.8W |
| X-ray dose per inspection | < 5 μGy |
| X-ray leakage | < 1μGy/h |
| X-ray generator | Anode Voltage: 140KV standard(Default shipping model), 160 KV optional, 100% Oil Cooling, Single generator, vertical beam direction |
