| Power Supply | 220 VAC (+ 10% to 15%), 50 Hz (±3 Hz) |
| Working Temperature | 5 °C to 40 ° C (41 °F to 104 °F) |
| Working Humidity | 0% to 90% |
| Dimension (W × H × D) | 2456 mm x1348 mm x 1331 mm (96.69" x 53.07" x52.40") |
| Operation System | windows |
| Tunnel Size | 660mm Wx502 mm H |
| Max. load | 150 kg (330.69 lb) |
| Conveyor speed | 0.22 m/s |
| Penetration | 34mm standard, 40+ mm available by customize |
| Wire resolution | 38AWG Standard, 40AWG by customize |
| Spatial resolution | bottom view : Vertical: 1.0 mm (0.04")；Horizontal: 1.0 mm (0.04\") side view : Vertical: 1.0 mm (0.04)；Horizontal: 1.0 mm (0.04\") |
| Power Consumption | 1 kw |
| X-ray dose per inspection | < 3.5 μGy |
| X-ray leakage | < 0.5μGy/h |
| X-ray generator | Anode Voltage: standard 160 kV, 100% Oil Cooling, Generator 1, vertical beam direction. Generator 2, horizontal beam direction. |
