| Power Supply | 220 VAC (+ 10% to 15%), 50 Hz (±3 Hz) |
| Working Temperature | 5 °C to 40 ° C (41 °F to 104 °F) |
| Working Humidity | 0% to 90% |
| Dimension (W × H × D) | 2195mm x 902 mm x 1362.5 mm (86.42" x 35.51" x 53.64") |
| Tunnel Size | 659.4mm Wx504 mm H |
| Max. load | 150 kg (330.69 lb) |
| Conveyor speed | 0.22 m/s |
| Penetration | Standard 8 mm, 11mm by customize |
| Wire resolution | 40AWG |
| Spatial resolution | Vertical: 1.0 mm (0.04") Horizontal: 1.0 mm (0.04) |
| Power Consumption | 0.8 kw |
| X-ray dose per inspection | < 3.5 μGy |
| X-ray leakage | < 0.5 μGy/h |
| X-ray generator | Anode Voltage: Standard 80 kV, 100% Oil Cooling |
